    Mimaki CG-160FXII Vinyl Cutter and Stand

    RRP £5,995.00


    Picture of Mimaki CG-160FXII Vinyl Cutter and Stand

    Mimaki CG-160FXII Vinyl Cutter and Stand

    Xpres Plus - VIEW OUR SITE DEDICATED TO VOLUME PRODUCTION SOLUTIONS!

    Virtual demo available - call to book!

    RRP £5,995.00

    This 160cm wide Mimaki cutting plotter provides a practical and cost effective solution for every sign and graphics need.

    SKU: XP1902
    Brand: Mimaki

    This 160cm wide Mimaki cutting plotter provides a practical and cost effective solution for every sign and graphics need.

    Products specifications
    Width 213cm
    Height 70cm
    Length 122cm
    Quantity per pack 1
    Extra Information 1. Max. sheet feeding length differs depending on the software
    Extra Information 2. Max. moving speed at 45° direction with pen up
    Extra Information 3. Depending on the specified film and cutting conditions
    Extra Information 4. Provided that the blade specific for fluorescent type vinyl or for reflective sheet are used
    Extra Information 5. The goods on the market are 8 – 9 mm pen. No guarantee on accuracy
    0.0 0
    Write your own review Close
    • Product can be reviewed only after purchasing it
    • Only registered users can write reviews
    *
    *
    • Bad
    • Excellent
    Downloads

    Finance



    Finance options are available for the loading.... These may vary on a case by case basis and should be discussed with a member of the Xpres team.

    Xpres are not the lender, but are acting on the customers behalf to arrange contact between our finance partners.









    Enquire About Finance

    *
    *
    *
    Technical Information
    • Acceptable sheet width: 9–188cm
    • Effective cutting area (1): 1600mm x 51m
    • Max. speed (2): 140cm/s
    • Max. cutting speed: 100cm/s
    • Repeatability: ± 0.2 mm (excluding shrinkage / expansion caused by film temperature)
    • Guaranteed range of accuracy (3): 1600mm x 10m
    • Max. pressure:400g
    • Acceptable sheet (4): Vinyl up to 0.25 mm thickness, fluorescent type vinyl, reflective sheet
    • Applicable tools (5): Cutter, water-based ball-point pen, oil-based ball-point pen. Also pouncing tool for CG-SRII and CG-FXII series.
    • Interface: USB, RS-232C
    • Power consumption: AC100V-240V, 130VA or less
    • Dimensions (WxDxH): 2125 x 700 x 1217mm
    • Weight: 69kg

    1. Max. sheet feeding length differs depending on the software
    2. Max. moving speed at 45o direction with pen up
    3. Depending on the specified film and cutting conditions
    4. Provided that the blade specific for fluorescent type vinyl or for reflective sheet are used
    5. The goods on the market are 8 – 9 mm pen. No guarantee on accuracy

    For further details of the Mimaki CG-160FXII download the PDF brochure using the attachment button above.

    Please note: this item will require specialist delivery and installation which we will have to arrange with the customer, additional costs may occur.
